Rainbow Vacuum E2 Type 12 Gold Series v1 Main Housing Parts

This category covers the complete Rainbow e2 Gold version 1 main housing that includes the face plate, rear cover assembly, latches, and HEPA filter.

This DOES NOT cover the sound reduction version so be sure to confirm what version you have.

Effective serial number 01000000 with a start date of September 4th 2003 through serial number 01187449 and an end date of January 12th 2006.

Serial number ranges shown are for units sold in the US. The range can differ for units sold outside the US.

Click on any number in the schematic below for details.

Tap + or pinch to zoom in, drag to move, then tap a number.

Rainbow Vacuum E2 Type 12 Gold Series v1 Main Housing Parts
#ImageItem NameItem #PriceQuantity
1 Main Housing, e2 (Gold) R12526 $90.35
2a Applique, Main Housing, Left, eSERIES R7879 $1.37
2b Kit, Gold Applique R13800K
3a Applique, Main Housing, Right, eSERIES R7880 $1.37
3b Kit, Gold Applique R13800K
4 Baffle Plate Asm, Right, E2 R12101
5 Baffle Plate Asm, Right, E2 R12101
6 Latch, E2 R8063 $10.53
7 Pin, Latch, E2 R7139 $2.10
8 Spring, Latch, E2 R7141 $4.29
9 Baffle Plate Asm, Left, E2 R8064
10 Baffle Plate Asm, Left, E2 R8064
11 Latch, E2 R8063 $10.53
12 Pin, Latch, E2 R7139 $2.10
13 Spring, Latch, E2 R7141 $4.29
14 Interlock Plunger, E2 R7208 $1.14
15 Switch, Interlock, E2 R7370 $7.83 $4.82
16 Gasket, Water Pan Neck, E2 R10534 $10.53
17 Screw, #8-10 x .50 Inch, E2 H580 $0.26
18 Face Plate Asm, E2 R12068 $38.45
19a Rear Cover Asm, E2 R10597
Alternative
19b Rear Cover Asm, E2 (Black) R14447 $26.62
20 Exhaust Cover, E2 R13430 $7.31
21 HEPA Filter, E2 R12179 $41.58 $36.04
22 Water Pan, 2.5 Qt, E2 R10236 $50.40
23 Airflow Adaptor, E2 R14422 $15.86
24a Receptacle, Integrated, P/Nozzle, E2 R12834 $7.44
24b Receptacle Harness, P/Nozzle, E2 R12017
Alternative
