Rainbow Vacuum AquaMate Model AM-12 Silver Series Parts
4.9 out of 5 based on 62 reviews
Version 2
Version 1
Never worry about those impossible stains again thanks to the power of the AquaMate III! This unbelievably powerful wide-angle attachment can lift stains like oils, grease, and even pet messes.
Below are images breaking down the complete AM-12 Silver version AquaMate. Click on each area of the system to get a more in-depth view.
This model has two different versions. The first version has two valves for water and soap. The second version has one valve for both.
Effective serial number 00001000 with a start date of July 30th 2007, through serial number 30000000 and end date of March 9th 2011.
Serial number ranges shown are for units sold in the US. The range can differ for units sold outside the US.
- Version 2This schematic covers the complete single valve design assembly that includes the brush roll, tank assembly, and front lens.
Effective serial number 00143500 with a start date of August 24th, 2009, through serial number 30000000 and an end date of March 9th 2011.
View Parts - Version 1This schematic covers the complete dual-valve design assembly, including the brush roll, tank assembly, and front lens.
To confirm, version ONE has a separate pedal for the shampoo solution and one for the clean rinse water.
On some labels,...
Effective serial number 00001000 with a start date of July 30th 2007, through serial number 00143499 and an end date of August 23rd, 2009.
View Parts
